FRP Septic Tank

Fiberglass GFRP FRP Septic Tank for residential community office building FT-STT1

Share:

Manufactured using Sheet Molding Compound (SMC) material, this septic tank is formed under high temperature and high pressure using a large hydraulic press. This advanced molding process results in a product with superior material density, uniform wall thickness, and precise dimensions, distinguishing it from traditional hand-layup or filament-wound tanks.

Hebei Fortis Technology Co., Ltd

Product Advantages

1. Leak-proof, acid and alkali resistant, safe for use, durable and robust.

Made of synthetic resin, glass fiber and other high-strength, acid and alkali resistant polymer materials, it is manufactured via one-piece high-strength mechanical compression molding.

2. Fast Construction and Easy Installation

The construction speed is fast, and it can be installed and put into use on the same day. On site, only the foundation pit needs to be excavated as required, and it can be put into use two hours after installation, which is convenient for rushing the construction period and avoiding the situation of foundation pit collapse due to time delay.

3. No special management required; long sludge cleaning interval.

With an underground installation design, it requires no power supply, no special management, and almost no maintenance. It is recommended to remove sludge once every 5 to 9 months.

4. Pollution-free in use with high environmental benefits.

The glass fiber reinforced plastic (FRP) septic tank is manufactured via compression molding, featuring excellent sealing performance and leak-proof integrity. It does not contaminate surface water nor corrode the surrounding environment (such as flowers, plants and trees). After multiple sedimentation and fermentation processes in the tank, parasite eggs and pathogens are effectively eliminated, and the effluent from the clarification chamber is purified, harmless organic fertilizer.

Application Scenarios

Applicable to the treatment and reuse of domestic sewage in residential districts, villages, towns, office buildings, shopping malls, hotels, restaurants, sanatoriums, government agencies, schools, military camps, hospitals, expressways, railways, factories, mines, tourist attractions and other places.

Treatment and reuse of industrial organic wastewater from small and medium-sized enterprises (SMEs) such as slaughtering, aquatic product processing, and food processing industries.

Parameter Specifications

Product

FRP Septic Tank

Fiberglass GFRP FRP Septic TankFiberglass GFRP FRP Septic Tank

Model

Volume(m³)

External dimensions(mm)

Length × Width × Height

Internal dimensions(mm)

Length × Width × Height

Avg. Thickness

(mm)

Weight
(kg)

FT-STT1

1

1740×1000×1000

1640×900×896

3.5

58

FT-STT1.5

1.5

1880×1015×1230

1808×943×1150

5

95

FT-STT2a

2

2000×1270×1292

1900×1170×1192

5

100

FT-STT2b

2

2370×1162×1190

2289×1081×1090

7

138

FT-STT2.5a

2.5

2448.5×1268.5×1302

2364.5×1184.5×1202

7

180

FT-STT2.5b

2.5

2470×1280×1300

2380×1190×1200

7

180

Model

Accessories

partition plate

screws

rubber strip

rubber gasket

cover

FT-STT1

2

18 (Φ6*25)

2.5

2 (Φ110mm)

2 or 3

FT-STT1.5

2

38 (Φ8*40)

3

0 (Φ110mm)

/

FT-STT2a

2

28 (Φ8*40)

3.5

2 (Φ110mm)

2

FT-STT2b

2

64 (Φ8*40)

3.5

1 (Φ110mm)

3

FT-STT2.5a

2

68 (Φ8*40)

4

0

3

FT-STT2.5b

2

56 (Φ8*40)

4

1 (Φ110mm)

3
