Our FRP Agitator Tank (Fiberglass Reinforced Plastic mixing vessel) is engineered to replace stainless steel, rubber-lined, or PP tanks in highly corrosive mixing applications. Traditional metal tanks suffer from pitting, chloride stress corrosion cracking, and metal ion leaching — contaminating sensitive batches and requiring costly replacement every 2–3 years.
Manufactured by filament winding or hand lay-up with ISO polyester/vinyl ester/epoxy resin, our FRP agitator tank offers complete corrosion resistance to over 300 chemicals including strong acids (H₂SO₄, HCl, HNO₃), alkalis (NaOH, KOH), salts, and organic solvents. The seamless, monolithic construction eliminates weak points. The inner surface is smooth (roughness ≤0.3mm) and can be lined with anti-corrosion veil for extra protection. We integrate industrial agitators (top entry, side entry, or bottom entry) with customized impeller types — turbine, propeller, anchor, or paddle — matched to your viscosity and mixing duty. Operating temperature range: -10°C to 100°C (resin dependent). Available volume: 200L to 150m³. It is the ideal mixing tank for chemical processing, hydrometallurgy, water treatment, electroplating, and pharmaceutical intermediates where purity and corrosion resistance are critical.
Hebei Fortis Technology Co., Ltd Product Brochure
Product Advantages
Superior Chemical Resistance – Resists over 300 corrosive media including 98% sulfuric acid, 35% hydrochloric acid, 50% sodium hydroxide, and various solvents. No lining failure or pitting corrosion like metal tanks.
No Metal Ion Contamination – FRP is non-metallic and inert. Safe for electroplating solutions, pharmaceutical intermediates, food-grade chemicals, and ultrapure water where trace metal ions ruin product quality.
Lightweight & Lower Installation Cost – Only 15–20% weight of steel tank of same volume. Requires no heavy crane for large vessels. Reduces foundation load and civil work cost.
Customizable Agitation System – Choose top entry, side entry, or bottom entry agitator. Impeller types: turbine (low viscosity mixing), propeller (high flow), anchor (high viscosity), paddle (gentle mixing). Motor: explosion-proof or VFD ready.
Seamless & Leak-proof Construction – Monolithic winding with no welds or joints. Double thickness at nozzle areas. 100% spark tested or hydrostatic tested before delivery. Zero leakage risk.
Long Service Life & Low Maintenance – Typical lifespan 15–20 years in continuous aggressive service. No repainting, no cathodic protection, no rubber lining replacement. Surface easily washable.
Temperature & Pressure Capable – Operating temperature -10°C to 100°C (vinyl ester up to 110°C). Design pressure from full vacuum to 5 bar (customizable).
FDA & WRAS Compliant Options – Food-grade resin and liner available for potable water, food, and beverage mixing applications.
