As a direct factory-exporter of FRP rods based in China, we engineer our pultruded profiles specifically to address the dual challenges of electrical insulation in high-voltage substations and corrosion fatigue in coastal architectural frameworks. Unlike standard rebar, our solid FRP rods deliver a dielectric strength exceeding 10 kV/mm and a flexural modulus of 40 GPa, verified by third-party SGS and ISO 9001:2025 protocols. We distinguish our export service through low MOQ (500 pcs) and tooling-free customization for knurled or threaded surfaces, ensuring your project timelines are met without sacrificing the structural integrity required for 25-year outdoor service life.
Hebei Fortis Technology Co., Ltd Product Brochure
Product Advantages
Superior Dielectric Insulation for High-Risk Electrical Environments
Unlike steel or aluminum, our solid FRP rods are inherently non-conductive and non-magnetic. They provide a reliable dielectric barrier in critical applications such as substation grounding grids, lightning arrestor down-conductors, and railway signal isolation zones. With a surface resistivity exceeding 10¹² Ω and a breakdown voltage that remains stable even in high-humidity conditions, these rods effectively eliminate stray current corrosion and eddy current heating—two silent killers that plague metallic components in AC/DC converter stations. This intrinsic insulation property drastically reduces unplanned maintenance shutdowns and enhances operator safety during live-line work.
Exceptional Anti-Corrosion Performance in Harsh Chemical and Marine Milieus
Our FRP rods are formulated with vinyl ester or isophthalic polyester resins, rendering them impervious to salt spray, acidic fumes, alkaline soils, and chloride-induced pitting. While galvanized steel rebar begins to rust within 200 hours in a salt fog test (ASTM B117), our rods show zero surface degradation after 3,000 hours of continuous exposure. This makes them the preferred choice for coastal retaining walls, desalination plant supports, chemical storage tank bracing, and underground trench covers where stainless steel would still suffer crevice corrosion. The result is a 25-year maintenance-free service life with no need for protective coatings or cathodic protection systems.
Parameter Specifications
|
Product |
FRP Rod / Solid Bars / Support Rods |
||
|
|
|||
|
Model |
Diameter(mm) A |
Weight(kg/m) |
Length(mm) |
|
FT-SR6 |
Φ6 |
0.05 |
Customized |
|
FT-SR6a |
Φ6.3 |
0.06 |
Customized |
|
FT-SR10 |
Φ10 |
0.15 |
Customized |
|
FT-SR12 |
Φ12 |
0.22 |
Customized |
|
FT-SR16 |
Φ16 |
0.4 |
Customized |
|
FT-SR19 |
Φ19 |
0.51 |
Customized |
|
FT-SR25 |
Φ25 |
1.05 |
Customized |
|
FT-SR |
Customized |
Customized |
Customized |
|
Features |
FRP rod is a new type of material that represents the development direction of high performance and durability. It does not completely replace steel, but provides a better and longer lasting solution in those areas where steel performance is poor or there are special requirements. |
||
|
Application |
Civil engineering applications: Chloride corrosion protection for docks, breakwaters, and cross-sea bridges. Anti-icing salt usage on bridge decks, guardrails, and piers in designated areas. Chemical corrosion resistance for floors, water tanks, and structural components at chemical plants and wastewater treatment facilities. Electromagnetic insulation solutions for foundations in hospital MRI rooms, research laboratories, and radar stations. |
||
|
Geotechnical and underground engineering: slope reinforcement and foundation pit support for anchor rods and soil nails. |
|||
|
Other fields: power system used as composite cable support, insulated ladder. Blade reinforcement ribs for new energy wind turbines. Greenhouse supports for agriculture, forestry, animal husbandry and fishery, support rods for mariculture nets. |
|||
|
Payment |
T/T, Western Union. |
||
|
Service |
Customize and design the size and style according to requirements |
||
