Our stainless steel cooling tower is designed for demanding industrial environments where corrosion resistance, structural strength, and long service life are critical. Unlike traditional galvanized steel or FRP towers, the all-stainless steel construction ensures superior performance in high-humidity, chemical-laden, or high-temperature conditions.
Hebei Fortis Technology Co., Ltd Product Brochure
Product Advantages
Full Stainless Steel Construction – Available in SS304, SS316, or SS316L grades. Suitable for coastal areas, chemical plants, and food processing industries.
Superior Corrosion & Rust Resistance – No painting or anti-rust coating required. Resists acidic exhaust, salt spray, and industrial pollutants.
High-Temperature Endurance – Operates stably with inlet water temperatures up to 75°C (SS304) or 85°C (SS316L).
Robust Mechanical Strength – Withstands high wind loads, vibration, and thermal stress without deformation.
Modular & Custom Design – Crossflow or counterflow configuration. Single-tower flow rate from 50 m³/h to 4,000 m³/h.
Fireproof & Low Maintenance – Class A fire rating. No aging, cracking, or UV degradation over time.
Application Scenarios
Central air conditioning system: Refrigeration station for commercialbuildings, hotels and hospitals.
Industrial refrigeration: processcooling for food processing, chemi-cal, pharmaceutical and plastic in-dustries.
Power industry: auxiliary coolingsystem for thermal power plant andnuclear power plant.
Manufacturing industry: circulating water cooling for metallurgical and mechanical processing plants.
Parameter Specifications
|
|
||||||||||
|
Product |
Square Cross Flow Cooling Tower |
|||||||||
|
Model |
τ=28℃ |
Main Dimensions (mm) |
Air Volume m³/h |
Fan Diameter (mm) |
Motor Installed Capacity (kw) |
Weight (t) |
τ=28℃ |
Noise at standard point |
||
|
Total Height |
Length× |
self-weight |
operating weight |
|||||||
|
AHBLD/HBLD-300 |
300 |
4514 |
7250× 3810 |
167000 |
3400 |
7.5 |
5.85 |
13.38 |
/ |
59.0 |
|
AHBLD/HBLD-500 |
500 |
5230 |
8033× 4650 |
260000 |
4200 |
11.0 |
9.2 |
17.24 |
/ |
61.5 |
|
AHBLD/HBLD-700 |
700 |
5319 |
8930× 6640 |
370000 |
5000 |
18.5 |
12.95 |
26.05 |
/ |
62.6 |
|
AHBLCD/HBLCD-300 |
300 |
6230 |
10650× 3810 |
167000 |
3400 |
7.5 |
7.05 |
14.18 |
/ |
52.5 |
|
AHBLCD/HBLCD-500 |
500 |
7030 |
11640× 4650 |
260000 |
4200 |
11.0 |
10.8 |
18.84 |
/ |
53.7 |
|
AHBLCD/HBLCD-700 |
700 |
7180 |
12540× 6640 |
370000 |
5000 |
18.5 |
14.75 |
26.81 |
/ |
54.5 |
|
AHBLG/HBLG-300 |
/ |
4514 |
7250× 3810 |
200000 |
3400 |
11.0 |
6.13 |
13.66 |
300 |
64.5 |
|
AHBLG/HBLG-500 |
/ |
5230 |
8033× 4650 |
320000 |
4200 |
18.5 |
9.42 |
17.46 |
500 |
65.0 |
|
AHBLG/HBLG-700 |
/ |
5319 |
8930× 6640 |
450000 |
5000 |
30.0 |
13.19 |
26.29 |
700 |
66.0 |
|
The standard point noise is measured at a distance equal to the equivalent diameter of the air inlet window or its shield equivalent diameter, and 1.5 meters above the ground. The equivalent diameter Dₘis calculated by the formula: Dₘ= 1.13×Length×Width |
||||||||||
|
Features |
The FRP cooling tower serves not only as a temperature regulator but also delivers an efficient, durable, and maintenance-free solution with optimized lifecycle costs. By harnessing the unique properties of FRP materials, it fundamentally addresses the critical challenges of corrosion and lifespan limitations in harsh operating environments, making it the go-to choice for cooling systems in modern industrial and commercial facilities. |
|||||||||
|
Application
|
Central air conditioning system: refrigeration station for commercial buildings, hotels and hospitals. |
|||||||||
|
Industrial refrigeration: process cooling for food processing, chemical, pharmaceutical and plastic industries. |
||||||||||
|
Power industry: auxiliary cooling system for thermal power plant and nuclear power plant. |
||||||||||
|
Manufacturing industry: circulating water cooling for metallurgical and mechanical processing plants. |
||||||||||
|
Data center: Provides cooling water for server rooms. |
||||||||||
|
Payment |
T/T, Western Union. |
|||||||||
|
Service |
Customize and design the size and style according to requirements |
|||||||||
