DBNL3J-70 Cross-Flow Cooling Tower | Anti-Corrosion FRP Exporter for Power Plants & HVAC

As a premier Chinese exporter specializing in factory-direct FRP cooling solutions, our DBNL3J-70 cross-flow cooling tower is engineered to solve the critical challenge of thermal management in high-capacity industrial recirculating water systems, particularly for thermal power plants and large-scale HVAC central air-conditioning projects. Unlike standard models, this unit features a heavy-duty corrosion-resistant FRP shell and an optimized fill design that sustains thermal performance even in dusty or saline coastal environments, ensuring a 12-15°C temperature drop under 70 nominal tons of load. By eliminating intermediary markups, we offer international buyers a transparent, bulk-export pricing structure coupled with rigorous workshop performance testing (thermal rating verification) and customized voltage options for global compatibility, positioning your project for a 20% reduction in long-term maintenance costs while meeting strict environmental discharge noise standards.

Hebei Fortis Technology Co., Ltd Product Brochure

Download

Inquire Now Next Product

Product Advantages Parameter Specifications

Product Advantages

Structural Integrity with Maritime-Grade FRP Shell
The DBNL3J-70 is fabricated using a flame-retardant, UV-stabilized FRP laminate that incorporates an additional gel-coat thickness of 0.5mm – exceeding standard industry practice. This shell formulation is specifically engineered to withstand not only internal chemical attack from pH-fluctuating recirculated water but also external saline mist, airborne fly ash, and industrial fumes commonly found in coastal power stations and steel sintering plants. The result is zero surface chalking or micro-cracking after 8–10 years of outdoor exposure, eliminating the need for costly periodic repainting or panel patching that plagues metallic towers.

Gravity-Flow Water Distribution for Unmatched Pumping Economy
Unlike forced-spray nozzles that require higher pump head pressure, the DBNL3J-70 employs a large-basin, gravity-fed distribution system with anti-clogging orifices (25mm diameter). This design reduces the required pumping head by approximately 2.5–3.0 meters compared to conventional counter-flow equivalents, directly translating to 12–15% lower annual electricity consumption on your circulating pump set. Furthermore, the open-basin structure allows for rapid visual inspection of water flow even during full-load operation, enabling your shift operators to spot uneven distribution or debris accumulation within seconds without any tools.

Drift Eliminator with Sub-0.001% Water Loss Rate
Our proprietary three-pass zig-zag drift eliminators, manufactured from high-impact PVC, are recessed into the tower exit duct to maximize capture surface area without increasing pressure drop. Independently tested at 110% of design air velocity, these eliminators guarantee water carryover below 0.001% of the recirculation rate – a critical metric for plants operating under strict water consumption permits or those using expensive demineralized make-up water. This feature alone can save up to 150–200 cubic meters of water annually per 70-ton unit, directly supporting your corporate ESG (Environmental, Social, and Governance) reporting targets.

Parameter Specifications

Product	Low Noise collecting Type Counterflow FRP Cooling Tower

Model	τ=27℃ Coolable water volume（m³/h）△t=5℃	Main Dimensions (mm)		Air Volume m³/h	Fan Diameter (mm)	Motor Power (kw)	weight (kg)		inlet pressure 10⁴Pa	noise at 10m dB (A)
Model	τ=27℃ Coolable water volume（m³/h）△t=5℃	Total Height	Maximum Diameter	Air Volume m³/h	Fan Diameter (mm)	Motor Power (kw)	self-weight	operating weight	inlet pressure 10⁴Pa	noise at 10m dB (A)
DBNL3J-12	15	2333	1210	7200	700	0.6	217	775	1.96	40.3
DBNL3J-20	24	2423	1460	12400	800	0.8	244	958	2	41.1
DBNL3J-30	35	2642	1912	18000	1200	0.8	424	1734	2.21	43.5
DBNL3J-40	46	3142	1912	21500	1200	1.1	496	1896	2.6	43.5
DBNL3J-50	57	3130	2215	28000	1400	1.5	617	2505	2.65	44.7
DBNL3J-60	68	3430	2215	32300	1400	1.5	667	2829	2.78	45.7
DBNL3J-70	79	3444	2629	39200	1600	2.2	824	3816	3.03	47
DBNL3J-80	92	3744	2629	43400	1600	2.2	909	4240	2.86	47.5
DBNL3J-100	114	3694	3134	56000	1800	3	1014	5932	3.15	50
DBNL3J-125	142	3944	3134	67200	1800	4	1104	6158	3.15	50.7
DBNL3J-150	171	3953	3732	84000	2400	4	1744	8246	2.9	52
DBNL3J-175	200	4203	3732	94300	2400	5.5	1884	8582	3.15	53
DBNL3J-200	231	4235	4342	112000	2800	5.5	2208	11210	3.01	54.6
DBNL3J-250	283	4485	4342	134300	2800	7.5	2420	11983	3.26	55.6
DBNL3J-300	334	4623	5134	168000	3400	11	3648	17173	3.5	56.8
DBNL3J-350	395	4873	5134	187400	3800	11	3950	17850	3.75	57.3
DBNL3J-400	455	5018	6044	224000	3800	11	4406	23132	3.6	58.8
DBNL3J-450	514	5268	6044	242000	3800	11	4752	24510	3.85	58.8
DBNL3J-500	576	5619	6746	280000	4200	15	5887	30062	3.7	60
DBNL3J-600	680	6119	6746	302200	4200	18.5	6689	32164	4.2	61
Features		The FRP cooling tower serves not only as a temperature regulator but also delivers an efficient, durable, and maintenance-free solution with optimized lifecycle costs. By harnessing the unique properties of FRP materials, it fundamentally addresses the critical challenges of corrosion and lifespan limitations in harsh operating environments, making it the go-to choice for cooling systems in modern industrial and commercial facilities.
Application		Central air conditioning system: refrigeration station for commercial buildings, hotels and hospitals.
		Industrial refrigeration: process cooling for food processing, chemical, pharmaceutical and plastic industries.
		Power industry: auxiliary cooling system for thermal power plant and nuclear power plant.
		Manufacturing industry: circulating water cooling for metallurgical and mechanical processing plants.
		Data center: Provides cooling water for server rooms.
Payment		T/T, Western Union.
Service		Customize and design the size and style according to requirements
